how to use auxiliary objective lens barlow lens

0 minutes, 49 seconds Read

what is auxiliary objective lens

An auxiliary lens (also called a “Barlow” lens or “objective” lens, (it is enclose external,different from the integrated objective lens),the functon is to increase or decrease the total magnification of a microscope, or increase or decrease its working distance.

Auxiliary lenses also cause a corresponding increase or decrease in working distance.
Mounting a lens that increases total magnification would result in a shorter working distance, while mounting one that decreases magnification would result in a longer working distance.

auxiliary objective lens increase decrease data

magnification/work distance/Magnification/ work distance.
0.3X   287MM  decrease magnification, increase Work distance;
0.5X   165MM  decrease magnification, increase Work distance;
0.7X   120MM  decrease magnification, increase Work distance;
0.75X 120MM decrease magnification, increase Work distance;
1.5X   45MM    increase magnification, decrease Work distance;
2X     30MM    increasemagnification, decrease Work distance;

how to use auxiliary objective lens barlow lens

attached the picture show how to fix the objective lens .

auxiliary objective Lens
Barlow Lens installation
